Product model : X15 AT 23
Model description : i7 13700HX+RTX4060+16GB+512GB;QHD/165Hz;Blue;15.6inch;N72
Product Collection : 13th Gen Intel® Core Mobile Processors i7
technology : Intel 7（10nm Enhanced SuperFin）
Total Processor Threads : 24
Max Turbo Frequency (GHz) : 5.0 GHz（P Core： 5.0GHz，E Core：3.7GHz）
Processor Base Frequency (GHz) : P Core： 2.1GHz，E Core：1.5GHz
TDP : 55W（Base Power）
Intel® Smart Cache (L3) : 30MB（L3）
Processor Graphics : Intel UHD Graphics
Graphics Card : NVIDIA-GeForce RTX 4060
NVIDIA Architecture : NVIDIA Ada Lovelace
Boost Clock (MHz) : 1470 - 2370 MHz
Tensor Cores : 4rd generation
Ray Tracing : Support
RT Core : 3rd generation
GPU Shaders : 3072
TDP (watts) : 140W（Max）
Max GPU temperature : 87℃
Standard Memory Config : GDDR6
VRAM Size : 8 GB
Memory Interface Width : 128Bit
DDR memory version : SODIMM DDR5
Memory Frequency : 4800MHz
Memory size : 16G（Single）
SSD : 512G（NVMe PCIe Gen3.0*4）
Connectivity : M.2 2280 M-Key
buses (channels) : NVMe PCIe Gen4.0*4
Screen size :15.6
Refresh rate : 165Hz
Resolution\gamut\ brightness : 2560x1440（QHD）\72%NTSC \300cd/m²
Wi-Fi version : Intel® Wireless-AX 211
TX/RX Streams : 2x2
CERTIFICADO PARA Wi-Fi* : 802.11ax，Wi-Fi6E
Bandas : 2.4GHz/5G Hz/6GHz(160MHz)
Tipo de interfaz de sistema : M.22230
Bluetooth : Bluetooth V5.3
USB :
Type A :1 x USB 3.2 Gen2
1 x USB 2.0
Type C : 1×USB 3.2 Gen 2
Thunderbolt :
TBT3/4 : 1×Thunderbolt 4
Video :
HDMI™ : 1 x HDMI™ output port (with HDCP) 2.1
Mini DP : 1 x Mini Display port 1.4
Audio :
Headphone/ Microphone : 1 x 2-in-1 Audio Jack (Headphone / Microphone)
1 x Microphone Jack
Size : 4.41KG
Carton dimensions : 510（L) x 108 (W) x 335 (H) mm
Warranty Card、Certificate of Conformity、Instruction manual
System : Genuine WIN11
Memory :
• 2×SO-DIMM(DDR5 4800，Single 32G maximum)
• Already in use1×SO-DIMM
Hard Disk :
• 2 x M.2 ports PCIe Gen4 x 4 channels (bus) that support NVMe (RAID 0/1)
• A PCIe Gen4×4 channel (bus) with 1 x M.2 ports has been used, and RAID
0/1 supports NVMe
Screen : HDMI*1 / mini DP*1 / Thunderbolt*1
